Product information

Product details

The ASROCK device is a well-specified option designed for buyers who need reliable everyday performance. Whether you are working through documents, managing emails, video calling, or streaming content, it is built to handle the tasks most people actually use a device for, day in and day out.

Why You'll Like It

  • Supports 3rd Gen AMD AM4 Ryzen / future AMD Ryzen Processors (3000 and 4000 Series Processors) - gives you the processing headroom for responsive everyday use, smoother multitasking, and less waiting around when switching between tasks.
  • Supports Extreme Memory Profile (XMP) memory modules - helps the system stay smooth when you have multiple browser tabs, documents, emails, and meetings open at once.
  • 4 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1 and RAID 10), NCQ, AHCI and Hot Plug 1 x Ultra M.2 Socket, supports M Key type 2242/2260/2280 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen3 x4 (32 Gb/s) - delivers quicker startup times, snappier application loading, and fast access to everyday files.
  • Complete with two types of most used connectors! Packed with a D-Sub + HDMI combo, you have more graphics output options now. - supports smooth visual performance for business tasks, media playback, and general graphical workloads.
  • 128Mb AMI UEFI Legal BIOS with GUI support Supports "Plug and Play" - gives you a familiar, ready-to-use environment so you can get set up quickly and stay productive.

Perfect For

Particularly well suited to buyers who want reliable, practical technology for everyday use without getting lost in unnecessary jargon.

Product Features

  • Processor: Supports 3rd Gen AMD AM4 Ryzen / future AMD Ryzen Processors (3000 and 4000 Series Processors)
  • Memory: Supports Extreme Memory Profile (XMP) memory modules
  • Storage: 4 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1 and RAID 10), NCQ, AHCI and Hot Plug 1 x Ultra M.2 Socket, supports M Key type 2242/2260/2280 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen3 x4 (32 Gb/s)
  • Graphics: Complete with two types of most used connectors! Packed with a D-Sub + HDMI combo, you have more graphics output options now.
  • Operating System: 128Mb AMI UEFI Legal BIOS with GUI support Supports "Plug and Play"
  • Weight: 0.75 kg

FAQs

Q: Is this a good choice for everyday use?

A: Yes. This product is aimed at dependable day-to-day workloads, so it is a strong fit for the sort of browsing, documents, communication, and routine tasks most buyers actually need.

Q: Who is this best suited to?

A: It is best suited to buyers who want a practical, reliable option with sensible specifications and straightforward performance rather than paying extra for features they may never use.

Need help choosing?
Call 01392 330 292 or WhatsApp 07715428800 and we will help you choose the best option.

Technical information

Specifications

Full technical specifications for this product.

Performance

Dual Graphics Outputs
Complete with two types of most used connectors! Packed with a D-Sub + HDMI combo, you have more graphics output options now.
CPU
Supports 3rd Gen AMD AM4 Ryzen / future AMD Ryzen Processors (3000 and 4000 Series Processors)
Max. Capacity Of System Memory: 64GB
Supports Extreme Memory Profile (XMP) memory modules
Graphics
Integrated AMD Radeon Vega Series Graphics in Ryzen Series APU DirectX 12, Pixel Shader 5.0 Shared memory default 2GB. Max Shared memory supports up to 16GB. Dual graphics output: support D-Sub and HDMI ports by independent display controllers Supports HDMI 2.1 with max. resolution up to 4K x 2K (4096x2160) @ 60Hz Supports D-Sub with max. resolution up to 1920x1200 @ 60Hz Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI 2.1 Port (Compliant HDMI monitor is required) Supports HDR (High Dynamic Range) with HDMI 2.1 Supports HDCP 2.3 with HDMI 2.1 Port Supports 4K Ultra HD (UHD) playback with HDMI 2.1 Port Supports Microsoft PlayReady
Storage
4 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1 and RAID 10), NCQ, AHCI and Hot Plug 1 x Ultra M.2 Socket, supports M Key type 2242/2260/2280 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen3 x4 (32 Gb/s)
1 X CPU Fan Connector (4-pin)
2 x Chassis Fan Connectors (4-pin) (Smart Fan Speed Control)

Display

1 X Front Panel Audio Connector
2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD Protection) 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports) (Supports ESD Protection)

Connectivity

1 X COM Port Header
1 x Chassis Intrusion and Speaker Header
1 X HDMI Port
2 x USB 2.0 Ports (Supports ESD Protection) 4 x USB 3.2 Gen1 Ports (Supports ESD Protection) 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED) HD Audio Jacks: Line in / Front Speaker / Microphone Software and UEFI

Physical details

Form Factor
Micro ATX Form Factor: 9.0-in x 7.9-in, 23.0 cm x 20.1 cm

Other specifications

- High Density Glass Fabric PCB
ASRock Ultra M.2 (PCIe Gen3 x4 & SATA3) ASRock Full Spike Protection (for all USB, Audio, LAN Ports)
2 X DDR4 DIMM Slots
AMD Ryzen series CPUs (Matisse) support DDR4 4600+(OC) / 4533(OC) / 4466(OC) / 4400(OC) / 4333(OC) / 4333(OC) / 4266(OC) / 4200(OC) / 4133(OC) / 4000(OC) / 3866(OC) / 3800(OC) / 3733(OC) / 3600(OC) / 3466(OC) / 3200 / 2933 / 2667 / 2400 / 2133 ECC & non-ECC, un-buffered memory AMD Ryzen series APUs (Renoir) support DDR4 4733+(OC) / 4666(OC) / 4600(OC) / 4533(OC) / 4466(OC) / 4400(OC) / 4333(OC) / 4266(OC) / 4200(OC) / 4133(OC) / 4000(OC) / 3866(OC) / 3800(OC) / 3733(OC) / 3600(OC) / 3466(OC) / 3200 / 2933 / 2667 / 2400 / 2133 ECC & non-ECC, un-buffered memory
BIOS
128Mb AMI UEFI Legal BIOS with GUI support Supports "Plug and Play"
ACPI 5.1 Compliance Wake Up Events
Supports jumperfree SMBIOS 2.3 support CPU, CPU VDDCR_SOC, DRAM, VDDP Voltage Multi-adjustment
Audio
7.1 CH HD Audio (Realtek ALC887 Audio Codec) Supports Surge Protection
Realtek RTL8111H
Supports Wake-On-LAN Supports Lightning/ESD Protection Supports Energy Efficient Ethernet 802.3az Supports PXE
Slots
1 x PCI Express 3.0 x16 Slot (PCIE2: x16 mode)
- ASRock Instant Flash
Support CD Drivers, Utilities, AntiVirus Software (Trial Version), Google Chrome Browser and Toolbar
Accessories
Quick Installation Guide, Support CD, I/O Shield
2 X SATA Data Cables
1 x Screw for M.2 Socket
Hardware Monitor
Temperature Sensing: CPU, Chassis Fans Fan Tachometer: CPU, Chassis Fans Quiet Fan (Auto adjust chassis fan speed by CPU temperature): CPU, Chassis Fans Fan Multi-Speed Control: CPU, Chassis Fans
CASE OPEN Detection
Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore
Certifications
FCC, CE ErP/EuP ready (ErP/EuP ready power supply is required)
