Platform
Mini-ITX Form Factor: 6.7-in x 6.7-in, 17.0 cm x 17.0 cm
Superb Productivity
PCIe Gen5 (Graphics, M.2)
Rock-Solid Durability
10+1+1 Power Phase, 110A SPS for VCore with Enlarged Heatsink Armor
Ultrafast Gaming
Killer 2.5G LAN, 802.11axe Wi-Fi 6E Module
CPU
1 x Blazing M.2 Socket (M2_1, Key M), supports type 2280 PCIe Gen5x4 (128 Gb/s) mode
2 X DDR5 DIMM Slots
Supports DDR5 ECC/non-ECC, un-buffered memory up to 8200+(OC)
Max. Capacity Of System Memory: 128GB
Supports Extreme Memory Profile (XMP) and EXTended Profiles for Overclocking (EXPO) memory modules
Chipset
1 x Hyper M.2 Socket (M2_2, Key M), supports type 2280 PCIe Gen4x4 (64 Gb/s) mode
Graphics
Integrated AMD RDNA graphics (Actual support may vary by CPU) 1 x HDMI 2.1 TMDS/FRL 8G Compatible, supports HDR, HDCP 2.3 and max. resolution up to 4K 120Hz 1 x USB 3.2 Gen2 Type-C, supports DP 1.4 HBR3 and max. resolution up to 4K 60Hz (DP-alt mode supports DP1.4a)
Audio
7.1 CH HD Audio with Content Protection (Realtek ALC1220 Audio Codec)
Impedance Sensing On Rear Out Port
Individual PCB Layers for R/L Audio Channel
Killer E3100G
Supports Killer LAN Software
802.11axe Wi-Fi 6E Module
Supports IEEE 802.11a/b/g/n/ac/ax/axe Supports Dual-Band 2x2 with extended 6GHz band support Wi-Fi 6E (6GHz band) will be supported by Microsoft Windows 11. The availability will depend on the different regulation status of each country and region. It will be activated (for supported countries) through Windows Update and software updates once available. A 6GHz compatible router is required for 6E functionality. 2 x antennas to support 2 x (Transmit) x 2 (Receive) diversity technology Supports Bluetooth 5.2 Supports MU-MIMO
1 X USB 3.2 Gen1 Type-C (Front)
3 x USB 3.2 Gen1 Type-A (1 Rear, 2 Front) 6 x USB 2.0 (4 Rear, 2 Front) All USB ports support ESD Protection
1 X Optical SPDIF Out Port
2 x USB 3.2 Gen2 Type-A Ports (10 Gb/s) 1 x USB 3.2 Gen2 Type-C Port (10 Gb/s) (DP-alt mode supports DP1.4a.)
1 X BIOS Flashback Button
1 x Line Out Jack (Gold Audio Jack) 1 x Microphone Input Jack (Gold Audio Jack) USB32_23 are Lightning Gaming Ports. USB32_TC1 supports a maximum speed of 40 Gb/s as a USB4 port with the 8000 (Phoenix 1 and Phoenix 2) series processors.
2 X SATA3 6.0 Gb/s Connectors
M2_1 is the first priority for M.2 installation. M2_1 will run at Gen5x4 with 9000 and 7000 series processors and Gen4x4 with 8000 (Phoenix 1 and Phoenix 2) series processors. Supports NVMe SSD as boot disks
RAID
Supports RAID 0 and RAID 1 for SATA storage devices Supports RAID 0, RAID 1 and RAID 10 for M.2 NVMe storage devices Requires additional M.2 NVMe expansion cards to support RAID 10
2 X Addressable LED Headers
1 x CPU Fan Connector (4-pin) (Smart Fan Speed Control) 1 x Chassis Fan Connector (4-pin) (Smart Fan Speed Control) 1 x AIO Pump Fan Connector (4-pin) (Smart Fan Speed Control)
1 X 24 Pin ATX Power Connector
1 x 8 pin 12V Power Connector (Hi-Density Power Connector)
1 X Front Panel Audio Connector
1 x USB 2.0 Header (Supports 2 USB 2.0 ports) 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports) 1 x Front Panel Type C USB 3.2 Gen1 Header Support in total up to 5V/3A, 15W LED Strip CPU_FAN1, CHA_FAN1 and AIO_PUMP support the fan power up to 3A (36W). CPU_FAN1, CHA_FAN1 and AIO_PUMP can auto detect if 3-pin or 4-pin fan is in use.
BIOS Feature
256Mb AMI UEFI Legal BIOS with GUI support Software and UEFI ASRock Motherboard Utility (Phantom Gaming Tuning)
Certifications
FCC, CE ErP/EuP ready (ErP/EuP ready power supply is required)
2 X ASRock WiFi 2.4/5/6 GHz Antennas
2 x Screws for M.2 Sockets
